ROLLER COMPACTOR RENTALS

BRAND NAME ROLLERS & COMPACTORS BUILT TO LAST

RIDE ON ROLLER COMPACTOR RENTALS NEAR ME

QUICK MENU

Bomag BW100AD | Bomag BW120 | Volvo SD25D | Volvo SD45D

Bomag BW177D-5 | CAT 563C | Dynapac CC900G

CLICK ON THE MODEL TO VIEW

RIDE ON ROLLER COMPACTOR RENTALS NEAR ME

BOMAG BW100AD

The Bomag BW100AD asphalt compactor contains BOMAP: the new, self-explanatory, mobile solution that allows you to document your work results right on site in real time. This compactor features hydrostatic travel and vibration drive, 2 scrapers per drum, pressure sprinkler system with interval switch, multi function travel lever, multi-function display, emergency STOP, intelligent Vibration Control, vandalism protection, 12V socket, a back up alarm, and a lockable engine hood.

Field of Application

Asphalt compaction – to increase load-bearing capacity and wear resistance. New construction and repair work for medium to small building projects. The new series of tandem rollers < 5t offers best visibility and highest driving comfort. For compaction work with side restrictions (e.g. house walls) the rollers are also available with open-sided drums (BW90 SC/ 100 SC).
Technologies
Every application is different, and every construction site presents new challenges. Which is why asphalt compaction is not about the right philosophy, but the right technology! BOMAG lets you match your operation and your work. We provide the right technology for every application. All from one source.
- BOMAP is the new, self-explanatory, mobile solution that allows you to document your work results right on site in real time. Transparency that pays off.
- BOMAG ECONOMIZER shows the operator when optimum compaction has been achieved and makes soil and asphalt compaction transparent and efficient.
- Call up the status of your vehicles from your computer or tablet. Full transparency at all times for your machine fleet with the new BOMAG TELEMATIC app for PC, iOS and Android devices.
Standard Specs
- Travel drive in series
- Hydrostatic travel and vibration drive
- Multi function travel lever
- Emergency STOP
- Individual control, vibration
- Pressure sprinkler system with interval switch
- Multi-function display incl. operating hour meter
- Intelligent Vibration Control (IVC)
- Integrated storage compartment
- Adjustable operator's seat
- Water level
- Vandalism protection
- Seat contact switch
- 12V socket
- Working lights front and rear
- Back-up alarm
- Lashing eyes, galvanized
- Single point lifting device
- 2 scrapers per drum, spring loaded and tiltable
- Lockable engine hood made of composite material
BOMAG Quality

When you see BOMAG on a machine, you can expect real quality. This applies both to our original parts and our service. Opting for a BOMAG means choosing top quality every time. Original parts and service are there to protect your investment. They ensure 100% machine power and availability – and ultimately the productivity and cost-effectiveness of your company. BOMAG offers a range of service products to keep you on the road.

BOMAG BW100AD
Operating weight with ROPS CECE (lb)	5.732
Average static linear load CECE (lb/in)	72.8
Gross weight (lb)	7.496
Working width (in)	39.4
Track radius, inner (in)	100.4
Speed (mph)	0 - 6.2
Working speed with vibration (mph)	0 - 6.2
Max gradeablility without/with vibration (%)	40/30
Engine	KUBOTA D1803
Emission stage	Stage V / TIER4f
Exhaust gas after treatment	DPF
Cooling	Water
Number of cylinders	3
Perfomance ISO 14396 (hp)	33.0
Perfomance SAE J 1995 (hp)	33.0
Speed (min-1)	2.600

↓ SCROLL DOWN TO SEE MORE INFO ↓

CALL TO RESERVE

RIDE ON ROLLER COMPACTOR RENTALS NEAR ME

BOMAG BW120

The Bomag BW120 is ideal for asphalt compaction and contains BOMAP: the new, self-explanatory, mobile solution that allows you to document your work results right on site in real time. This compactor features an integrated stowage compartment, hydrostatic travel and vibration drive, 2 scrapers per drum, pressure sprinkler system with interval switch, multi function travel lever, multi-function display, emergency STOP, intelligent Vibration Control, vandalism protection, 12V socket, a back up alarm, and a lockable engine hood.

Field of Application

Asphalt compaction – to increase load-bearing capacity and wear resistance. New construction and repair work for medium to small building projects. The new series of tandem rollers < 5t offers best visibility and highest driving comfort. For compaction work with side restrictions (e.g. house walls) the rollers are also available with open-sided drums (BW90 SC/ 100 SC).
Technologies
Every application is different, and every construction site presents new challenges. Which is why asphalt compaction is not about the right philosophy, but the right technology! BOMAG lets you match your operation and your work. We provide the right technology for every application. All from one source.
- BOMAP is the new, self-explanatory, mobile solution that allows you to document your work results right on site in real time. Transparency that pays off.
- BOMAG ECONOMIZER shows the operator when optimum compaction has been achieved and makes soil and asphalt compaction transparent and efficient.
- Call up the status of your vehicles from your computer or tablet. Full transparency at all times for your machine fleet with the new BOMAG TELEMATIC app for PC, iOS and Android devices.
Standard Specs
- Travel drive in series
- Hydrostatic travel and vibration drive
- Multi function travel lever
- Emergency STOP
- Individual control, vibration
- Pressure sprinkler system with interval switch
- Multi-function display incl. operating hour meter
- Intelligent Vibration Control (IVC)
- Integrated storage compartment
- Adjustable operator's seat
- Water level
- Vandalism protection
- Seat contact switch
- 12V socket
- Working lights front and rear
- Back-up alarm
- Lashing eyes, galvanized
- Single point lifting device
- 2 scrapers per drum, spring loaded and tiltable
- Lockable engine hood made of composite material
BOMAG Quality

When you see BOMAG on a machine, you can expect real quality. This applies both to our original parts and our service. Opting for a BOMAG means choosing top quality every time. Original parts and service are there to protect your investment. They ensure 100% machine power and availability – and ultimately the productivity and cost-effectiveness of your company. BOMAG offers a range of service products to keep you on the road.

BOMAG BW120
Operating weight with ROPS CECE (lb)	6.063
Average static linear load CECE (lb/in)	64.2
Gross weight (lb)	7.716
Working width (in)	47.2
Track radius, inner (in)	96.5
Speed (mph)	0 - 6.2
Working speed with vibration (mph)	0 - 6.2
Max gradeablility without/with vibration (%)	40/30
Engine	KUBOTA D1803
Emission stage	Stage V / TIER4f
Exhaust gas after treatment	DPF
Cooling	Water
Number of cylinders	3
Perfomance ISO 14396 (hp)	33.0
Perfomance SAE J 1995 (hp)	33.0
Speed (min-1)	2.600

↓ SCROLL DOWN TO SEE MORE INFO ↓

CALL TO RESERVE

RIDE ON ROLLER COMPACTOR RENTALS NEAR ME

VOLVO SD25D

The Volvo SD25D contains a Kubota V2203-M Tier 4 engine and an operating weight of 5,648-5,919 lbs.

Performance Features
- Adjustable front drum scraper
- Cold starting aid
- Cup holder and storage
- Engine hood sloped for ONE METER by ONE METER operator visibility
- Hour meter gauge and fuel gauge with low fuel warning
- Hydraulic hoses inside drum frame for protection
- Isolated operator’s platform reduces fatigue; ergonomic design with seat, console, and controls all located within operator zone of comfort and reach
- Lug-type tire set track within drum width
- Oil level sight gauges for eccentric oil and hydraulic oil reservoirs
- Rear-hinged engine cover for service access
Safety Features
- Safety features include ROPS / FOPS, sear belt, seat belt warning system, back-up alarm, seat switch, emergency stop button, horn, safety rails, and grab handles
- Warning lights and audible alarms for air restriction, battery discharge, engine coolant temperature, engine oil pressure, and hydraulic oil temperature

VOLVO SD25D
Engine	KUBOTA V2203-M Tier 4
... SAE J1995 gross, kW	31,4
Drum width (mm)	1,050
Vibration frequency (Hz)	36,7
Vibration centrifugal force (kN)	55,6
Nominal amplitude SD25D / SD25F (mm)	1,38 / 1,2
Operating weight SD25D / SD25F (kg)	854/895

CALL TO RESERVE

RIDE ON ROLLER COMPACTOR RENTALS NEAR ME

VOLVO SD45D

The Volvo SD45D soil compactor features an operating weight of 10,597 lbs and an engine power of 63 kW.

VOLVO SD45D
Engine	KUBOTA V-360OT Tier 3
Operating weight CECE (kg)	4,807
Machine length (mm)	4,053
Machine width (mm)	1,550
Machine height - top of ROPS / FOPS (mm)	2,830
Wheelbase (mm)	2,400
Curb clearance (mm)	305
Drum width (mm)	1,372
Drum diameter (mm)	1,000
Vibration frequency (Hz)	31.7
Travel speed (km/h)	0 - 8.1

CALL TO RESERVE

RIDE ON ROLLER COMPACTOR RENTALS NEAR ME

BOMAG BW177D-5

The Bomag BW177D5 soil compactor contains a Kubota V3307 CR-T engine and an operating weight capacity of 14,551 lbs. 

Field of Application

Soil compaction – a key application in civil engineering to achieve sound foundations.For medium scale compaction tasks. D-version for compacting non-cohesive soils as well as hydraulically bonded materials. The D-series models are suited to compacting non-cohesive soils (sand, gravel, rubble), weakly cohesive soils and hydraulically bound materials. The PD-models are primarily used on strongly cohesive soils with a high water content.
Technologies
BOMAG single drum rollers set the standards. With our accumulated know-how, we are an innovation driver that sets the pace for an entire industry. Along the way we have developed numerous new technologies: from systems for measuring and controlling compaction like VARIOCONTROL, BCM 05 or Terrameter, to an efficient reduction of operating costs with ECOMODE and ECOSTOP.
- BCM manages and documents the compaction of an entire construction site. A tablet PC and a GPS receiver form the basis for creating complete compaction maps.
- BOMAP is the new, self-explanatory, mobile solution that allows you to document your work results right on site in real time. Transparency that pays off.
- The cumulative power of BOMAG innovation can be found in every engine. With Stage IV and Tier 4 final they comply with the highest exhaust regulations. The smart ECOMODE speed control not only saves up to 30 percent fuel, but also produces less noise. And with the optional ECOSTOP, the engine is shut down automatically after a defined period in idle speed. This also reduces fuel consumption and wear.
- BOMAG ECONOMIZER shows the operator when optimum compaction has been achieved and makes soil and asphalt compaction transparent and efficient.
- Call up the status of your vehicles from your computer or tablet. Full transparency at all times for your machine fleet with the new BOMAG TELEMATIC app for PC, iOS and Android devices.
- TERRAMETER has the technology to do far more than load plates. It allows BOMAG single drum rollers to become rolling load plates: surface area covering, in real time.
Standard Specs
- BOMAG ECOMODE
- Double pump system for travel drive (DH/PDH)
- Self locking differential
- Rear axle with twin spring accumulator brakes
- Hydrostatic travel and vibration drive
- Hydrostatic articulated steering
- Articulated joint lock
- Warning, information and operation displays
- Single lever control for travel and vibration
- Emergency STOP
- Warning horn
- Back-up warning system
- 2 Contact scrapers Plastic (D/DH)
- 2 Scrapers (PDH)
- Tractor tires (PDH)
BOMAG Quality

When you see BOMAG on a machine, you can expect real quality. This applies both to our original parts and our service. Opting for a BOMAG means choosing top quality every time. Original parts and service are there to protect your investment. They ensure 100% machine power and availability – and ultimately the productivity and cost-effectiveness of your company. BOMAG offers a range of service products to keep you on the road.

BOMAG BW177D5
Gross weight (lb)	17,196
Operating weight CECE with ROPS-cabin (lb)	14,551
Working width (in)	66.5
Track radius, inner (in)	117.1
Engine	KUBOTA V3307 CR-T Stage V / TIER4f
Cooling	Liquid
Number of cylinders	4
Speed (rpm)	1,372
Perfomance ISO 3049 (kW)	55.4
Performance SAE J.1995 (hp)	75.0
Fuel	Diesel

CALL TO RESERVE

RIDE ON ROLLER COMPACTOR RENTALS NEAR ME

CAT 536C

Unleash the power of precision and efficiency with the CAT 536C Ride-On Roller. This heavy-duty piece of machinery is designed to meet the toughest demands of road construction, site preparation, and other large-scale projects. The CAT 536C features a robust engine that provides an impressive horsepower, ensuring reliable performance even under the most challenging conditions. Its advanced hydraulic system delivers smooth and efficient operation, enabling you to complete tasks quickly and effectively.

This ride-on roller boasts an ergonomic operator station that offers exceptional comfort and visibility. The intuitive controls make it easy to operate, reducing operator fatigue and increasing productivity. The seat is adjustable and cushioned, providing optimal comfort for long hours of operation. The CAT 536C is also equipped with large, durable drums that provide excellent compaction performance. These drums are designed to deliver high compaction force, ensuring superior density levels on a wide range of materials, including soil, gravel, and asphalt.

CATAPILLAR 563C
Engine power (hp)	203.00
Engine model	C7.1 ACERT
Engine speed (rpm)	1,800
Wheelbase (in)	110
Operating weight without attachment (lb)	3,1060

CALL TO RESERVE

RIDE ON ROLLER COMPACTOR RENTALS NEAR ME

DYNAPAC CC900G 1 1/2 TON ROLLER

The Dynapac CC900G is a small asphalt roller with a drum width of 900 mm. This machine is equipped with a powerful petrol engine, which together with the large drum diameter and drive motors connected in series contributes to excellent accessibility and hill-climbing capacity. It's primarily used for small-scale compaction work such as pavements, cycle paths, small roads and small parking areas. Dynapac CC900G has vibration on the front drum and a static rear drum. This machine is not CE-certified.

DYNAPAC CC900G
Masses
Max. operating mass	1300 kg
Operating mass (incl. ROPS)	1250 kg
Module mass (front/rear)	545 kg/ 705 kg
Traction
Speed range	0-8 km/h
Vertical oscillation	±13°
Max. theoretical gradeability	35 %
Compaction
Centrifugal force	16.7 kN
Nominal amplitude	0.4 mm
Static linear load (front/rear)	6.1/ 7.9 kg/cm
Vibration frequency	70 Hz
Water tank volume	190 l
Engine
Manufacturer/Model	Honda GX630RH QYD
Type	4-stroke gasoline
Rated power, SAE J1995	14.2 kW (19 hp ) @ 3000 rpm
Fuel tank capacity	23 l
Hydraulic system
Driving	Axial piston pump with variable displacement.
2 radial piston motors with constant displacement.
Vibration	Gear pump/motors with constant displacement.
Steering	Gear pump with constant displacement.
Service brake	Hydrostatic in forward and reverse lever.
Parking/
Emergency brake	Failsafe brake in both drums.
